DPDT Power Relays 4

DPDT Power Relay Rating 120VAC @ 40A (N.O.) / 120VAC @ 30A (N.C.)

SPST Dry Contacts for Remote Signaling (BMS, BAS, or Other) 5

SPST Dry Contact Rating 24VDC @ .5A

SPST Dry Contact Functions (1) Power-loss, (4) Control Functions

LED Indicators: 5

Press to Test Yes

Audible Alarm: Available upon request

Alarm Beacon: Available upon request

Temperature Alarm: Available upon request

Rating: NEMA 4X (Indoor/Outdoor)

Material: Polycarbonate

Size: L: 10-1/2 "   W:  9-1/2"   H:  5"

Panel Door: Hinged, Non-Transparent ( Clear available upon request)

Latch: Stainless Steel (Lockable latch available upon request)

Panel Faceplates Aluminum

Plug Style 3" PVC Slip-Plug

Sensor Head Material: PVC

Sensor Head Size: 3" diameter (round)

Probe Material PVC Heat-Shrink, Stainless Steel

Probe Length: High Alarm (Green) 10-3/8"

 Fill Stop (Red) 14"

 Fill Start (White) 15-1/2"

 Low Alarm (Brown) 16-3/8"

 Reference (Black) 17"

 Temperature Probe (Orange)

Probes Extendable? Yes (18"/45.5" Extension Kits available)

Valves Available Jefferson (3/4"-2") OCV Valve (2"-12"), Superior Valve (3/4"- 2")

Extension Rod Kits

Audible Alarm

Top of Panel Beacon

H.O.A. Switches

Remote Indication Panels

Light Towers

Shipping Box Dimensions: (Info Not Available)

5-Year Limited Warranty

Life of Product Technical Support
